 The
IV-300 electronic ignition module is designed to achieve contact-free
ignition of air-fuel mixtures. This type of ignition module utilises
transistor switches for magnet activation. A key feature of this module is the very low revolution speed for start-up, which translates into an easy engine start. The modules are fabricated
to high standards at VEC’s own modern production facility. VEC uses
only high-quality components from globally established suppliers.
It all adds up to a long lifetime and reliable operation.
The IV-300 module is specified for installation in the IM300, IM350 and IM359 powered turf digger manufactured by either INTERMOTOR and in the A349 and A360 powered turf digger manufactured by either AKME.
All products supplied by VEC Ignitions are covered
by a five-year warranty. This warranty does not cover damages resulting
from improper installation and damages caused by mechanical actions.
|
 When
ordering an ignition module or component, make sure to specify the
correct model designation, in this case IV-300. Please let us know
if you intend to operate the modules under extreme temperature conditions.
We have special solutions for these cases.
Refer to the package specification page at the end of this catalogue.The electronic ignition module comes in a blister package (see sketch
S1) along with a high voltage cable and an ignition breaker cable.
Larger quantities of the IV-300 module come in appropriately sized
cartons (see sketches S2, S3, and S4).
|
